1080p looks awful
2242 15 2018-1-16
Uploading and Loding Picture ...(0/1)
o(^-^)o
MiniPalourde
Second Officer
Flight distance : 7 ft
United States
Offline

Hello,

A lot of people on here say that 1080p is surprisingly good, but when I tried it out for myself it wasn't sharp AT ALL and looked like it was taken by some 720p toy. Maybe because I was at high altitude (400 feet) and there was too many details? I would really like to try out 96 fps without losing so much quality.

Thanks
2018-1-16
Use props
Ex Machina
Captain
Flight distance : 1806362 ft
United States
Offline

Most of us prefer the higher resolution that 2.7/4K rates give you, unfortunately, anything over 30 fps at 1080 comes at the cost of degraded video quality.
2018-1-16
Use props
Dirty Bird
Captain
Flight distance : 12270610 ft
  • >>>
United States
Offline

Mavic Pro.  1080x30 fps.




2018-1-16
Use props
A CW
Captain
Flight distance : 13838848 ft
  • >>>
United Kingdom
Offline

I’ve noticed a big difference recording 1080p @ 60p between the original Mavic and my new Mavic Platinum. I thought this was due to recent FW updates between owning both but clearly not.
2018-1-16
Use props
MiniPalourde
Second Officer
Flight distance : 7 ft
United States
Offline


Yea your 1080p look fine but it's in 30 fps. I wish there was a way for good quality 60fps+
2018-1-17
Use props
MiniPalourde
Second Officer
Flight distance : 7 ft
United States
Offline

A CW Posted at 2018-1-16 23:35
I’ve noticed a big difference recording 1080p @ 60p between the original Mavic and my new Mavic Platinum. I thought this was due to recent FW updates between owning both but clearly not.

MPP's camera is different?
2018-1-17
Use props
Dirty Bird
Captain
Flight distance : 12270610 ft
  • >>>
United States
Offline

MiniPalourde Posted at 2018-1-17 06:38
Yea your 1080p look fine but it's in 30 fps. I wish there was a way for good quality 60fps+

1080x60 is unfortunately an issue with the Mavic Pro.
2018-1-17
Use props
Dirty Bird
Captain
Flight distance : 12270610 ft
  • >>>
United States
Offline

A CW Posted at 2018-1-16 23:35
I’ve noticed a big difference recording 1080p @ 60p between the original Mavic and my new Mavic Platinum. I thought this was due to recent FW updates between owning both but clearly not.

This is caused by the way the sensor used in the Mavic Pro handles antialiasing.  It was apparently corrected in the Platinum.

Mavic Pro 1080x60 Antialiasing Issue
2018-1-17
Use props
A CW
Captain
Flight distance : 13838848 ft
  • >>>
United Kingdom
Offline

Thanks for the info Dirty Bird. They have done something to the MPP camera for sure.
2018-1-17
Use props
Archie9
Second Officer
Flight distance : 47943 ft
Germany
Offline

Hello,

We performed cameratests on a test picture in 1080p with different Mavic Pro's in a German speaking Mavicforum: 1080p @ 30 @ 60 and @ 96fps.
The Mavics were from different Manufacturers date. Result: From Mavic Production Date 01/2017 there is no antialiasing or binning up to 60fps with only one exception.
So it seems that DJI has made Changes to the camera since 01/2017.
fly safe


2018-1-17
Use props
Hummingbird.UAV
Captain
Flight distance : 8146955 ft
  • >>>
Canada
Offline

Archie9 Posted at 2018-1-17 14:17
Hello,

We performed cameratests on a test picture in 1080p with different Mavic Pro's in a German speaking Mavicforum: 1080p @ 30 @ 60 and @ 96fps.

Sadly your German site won't let us look at the pictures.
PS I use 2.7K cause the 1080 is so bad.
2018-1-17
Use props
Archie9
Second Officer
Flight distance : 47943 ft
Germany
Offline

here the previous test results 1080@60fps:

08QD...A1RO       2016-09-..    Binning - Frannek (Reparatur)
08QD.......            2016-11-07  Binning - xbenderCH
08QD.......            2016-11-15  Binning - Arthur
...........                2016-11-..     Binning - DerKlotz
...........                2016-12-13   Binning - wolfs32
08QD...0120       2016-12-16   Binning - hawkins2000
08QD...0120       2016-12-31   Binning - mahendra
08QD.......           2017-01-10     OK    - Stevie69
...........                2017-01-20    OK    - Woodi
08QD...01..         2017-02-09    OK    - Charly2801 (Reparatur im September)
08QD.......           2017-03-08    OK    - foofighter188
08QD...0120       2017-03-14   Binning - mrg
08QD.......           2017-03-21    OK    - Schoasch
08QD...0120       2017-03-23    OK    - agm
08QU.......           2017-04-09    OK    - DirkSG
08QD...0120       2017-05-04    OK    - LuisCake
08QC...0120       2017-05-16    OK    - Harda
08QC...0120       2017-05-23    OK    - GrandSurf
08QC.......           2017-08-10    OK    - JeZe
08QU...10..         2017-08-14    OK    - makro01
08QC...0122       2017-08-17    OK    - archie

binning begins at 96 fps




1080@30fps

1080@30fps

1080@96fps

1080@96fps
2018-1-17
Use props
A CW
Captain
Flight distance : 13838848 ft
  • >>>
United Kingdom
Offline

Hummingbird.UAV Posted at 2018-1-17 14:42
Sadly your German site won't let us look at the pictures.
PS I use 2.7K cause the 1080 is so bad.

I record in 2.7K too 99% of the time. I'm more into stills anyway.
2018-1-17
Use props
MiniPalourde
Second Officer
Flight distance : 7 ft
United States
Offline

A CW Posted at 2018-1-17 15:03
I record in 2.7K too 99% of the time. I'm more into stills anyway.

From what I understand 2.7K looks better than 4K because it's not compressed as much?
2018-1-17
Use props
DJI Thor
Administrator
Flight distance : 13602 ft
Offline

When you shoot at 1080P 96fps, it will generate a slow-motion video. And for your case, do you mean that the video from the SD card looks terrible? If yes, please try to upload a sample from SD card to Dropbox so I can check. Thank you.
2018-1-17
Use props
Montfrooij
Captain
Flight distance : 2560453 ft
  • >>>
Netherlands
Online

Archie9 Posted at 2018-1-17 14:17
Hello,

We performed cameratests on a test picture in 1080p with different Mavic Pro's in a German speaking Mavicforum: 1080p @ 30 @ 60 and @ 96fps.

I had no issues (at least not too much).
Only some moire in expected places.
2018-1-18
Use props
